Coriolis Flow Meter YYCO Series

YOYI YYCO series product view

YOYI YYCO Series · direct mass flow, density and temperature

The Gold Standard of Mass Flow Measurement

The YOYI YYCO series Coriolis flow meter measures true mass flow directly, independently of fluid properties, and simultaneously outputs density and temperature. It is the instrument of choice for custody transfer, batching and any process where accuracy is revenue.

Turndown
up to 20:1
Density accuracy
±0.002 g/cm³
Hygienic option
Tri-clamp, polished
Outputs
4-20 mA, pulse, Modbus, Profibus

✓Exceptional accuracy up to ±0.1% of reading with 20:1 turndown for fiscal-grade duties.
✓Multi-variable output mass flow, volume flow, density and temperature from a single device.
✓Property-independent unchanged performance across viscosity, density and conductivity changes.
✓Hygienic options polished tubes and tri-clamp connections for sanitary processes.

Request a Quote View Models

Selection Guide

YYCO Series Model Range

Standard configurations are listed below. Custom liners, electrodes, connections and communication options are available on request.

Model	DN	Mass flow range	Pressure	Typical use
YYCO-6	DN6	0 – 600 kg/h	4.0 MPa	Additives, dosing
YYCO-15	DN15	0 – 4000 kg/h	4.0 MPa	Batching, food
YYCO-25	DN25	0 – 12000 kg/h	4.0 MPa	Chemical, pharma
YYCO-50	DN50	0 – 45000 kg/h	2.5 MPa	Loading, transfer
YYCO-80	DN80	0 – 120000 kg/h	2.5 MPa	Custody transfer
YYCO-100	DN100	0 – 200000 kg/h	1.6 MPa	Pipeline, marine

Higher pressure ratings, jacketed tubes for viscous fluids and hygienic executions are available. All meters ship with a factory calibration certificate.

Coriolis Flow Meter working principle diagram

How It Works

Fluid flows through one or two vibrating tubes. As mass moves along the tube, Coriolis forces twist it slightly, creating a phase shift between the inlet and outlet motion. That phase shift is directly proportional to mass flow.

The same oscillation also reveals the tube's natural frequency, which changes with fluid density — so one instrument gives mass flow, density and temperature simultaneously.

Technical Specifications

Diameter	DN6 – DN250
Accuracy	±0.1% liquids / ±0.35% gases
Turndown ratio	up to 20:1
Density accuracy	±0.002 g/cm³
Medium temperature	-50 °C … +200 °C
Pressure rating	up to 10.0 MPa
Output signal	4-20 mA / pulse / Modbus / HART / Profibus
Tube material	316L stainless steel, Hastelloy option
Protection class	IP67
Certificates	Calibration certificate, 3.1 material cert option

Typical Applications

Custody transferTruck loadingChemical dosingLPG & CO₂Pharma batchingDairy & syrupWell testingConcentration

Liquid custody transfer and truck loading, chemical dosing and blending, LPG and CO₂ measurement, pharmaceutical ingredient batching, dairy and syrup lines, and oil well test separators.

Get a YYCO quotation

Tell us fluid, line size, flow range and required output — we reply with a best-fit configuration within one business day.

Request a Quote Talk to an Engineer

✉ annie@yoyimeter.com

☎ +86 18027268785

Downloads

PDF

Technical DatasheetYYCO series · specifications & dimensions

PDF

Installation & Operation ManualWiring, commissioning and maintenance

PDF

Selection & Sizing GuideModel code builder and sizing worksheet

Documents are sent by email on request — the latest revision is always provided.

Why Choose the YYCO Series

✓Revenue-grade metering ready for custody-transfer applications with audit trail.
✓Two-in-one density replace separate density meters and infer concentration on-line.
✓Self-draining tubes perfect for hygienic and batch processes.
